| Item | Jobber Drill Bit |
|---|---|
| Aircraft Drill | Yes |
| Application | For Alloy, Stainless And Tool Steels And Cast Iron |
| Coolant Fed | Non-Coolant Through |
| Coolant Through | No |
| Cutting Direction | Right Hand |
| Decimal Equivalent | 0.041 |
| Depthdia. Ratio | 4Xd |
| Dimension Type | Wire Size |
| Drill Bit Dimension Type | Wire |
| Drill Bit Finish | Black Oxide |
| Drill Bit Grouping | Drill Bit |
| Drill Bit Material | High Speed Steel |
| Drill Bit Point Angle | 135° |
| Drill Bit Point Type | Split Point |
| Drill Bit Size | #59 |
| Drill Diameter Tolerance | -0" to +0.0005" |
| Drill Length Class | Jobber Length |
| Drill Point Length | 0.0085" |
| Finish | Black Oxide |
| Finish - Machining | Black Oxide |
| Flute Length | 11/16" |
| Flute Type | Spiral |
| Grade | High Performance |
| Helix Angle | 28° |
| Left/right Hand | Right |
|---|---|
| List Number | 150ASP |
| Material | High Speed Steel |
| Material - Machining | High Speed Steel |
| Material Grade - Machining | HIGH PERFORMANCE |
| Max. Drilling Depth | 1/2" |
| Maximum Drilling Depth | 1/8" |
| Measurement System | Wire |
| No. Of Pieces | 1 |
| Number Of Flutes | 2 |
| Overall Length | 1 5/8" |
| Point Angle | 135° |
| Point Type | Conventional Point |
| Primary Material Application | Cast Iron, Stainless Steel, Steel |
| Primary Material Application Iso Code | K, M, P |
| Series | 150ASP Series |
| Shank Dia. | 1/32" |
| Shank Length | 15/16" |
| Shank Type - Machining | Straight |
| Sheeter Drill | No |
| Size | #59 |
| Spiral Direction | Right Hand |
| Web Thinning | Thinned |
| Standards | NAS 907 TYPE B |
| Height (cm) | 2.54 |
|---|---|
| Length (cm) | 8.5 |
| Width (cm) | 5.84 |
| HS Code | 8207504060 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 0.045 |
| Style | Model | Decimal Equivalent | Finish | Drill Bit Size | Drill Bit Point Angle | Drill Bit Point Type | Flute Length | Overall Length | Shank Dia. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 44087 | 0.173 | Black Oxide | #17 | 118° | Conventional Point | 2 3/16" | 3 3/8" | - | $5.73 | |
| A | 44088 | - | Black Oxide | #18 | 118° | Conventional Point | 2 1/8" | - | - | $5.03 | |
| A | 44089 | 0.166 | Black Oxide | #19 | 118° | Conventional Point | 2 1/8" | 3 1/4" | - | $5.03 | |
| A | 44090 | 0.161 | Black Oxide | #20 | 118° | Conventional Point | 2 1/8" | - | - | $5.03 | |
| A | 44091 | 0.159 | Black Oxide | #21 | 118° | Conventional Point | 2 1/8" | - | 0.159" | $4.54 | |
| A | 44092 | 0.157 | Black Oxide | #22 | 118° | Conventional Point | 2" | 3 1/8" | 0.157" | $4.54 | |
| A | 44093 | 0.154 | Black Oxide | #23 | 118° | Conventional Point | 2" | 3 1/8" | - | $4.54 |
