| Item | Vector Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Base Indicator | Rigid |
| Base Rpm | 1800 RPM |
| Base Type | Rigid Base |
| Break-down Torque | 30 lbs.-ft. |
| Color | White |
| Conduit Box Material | Steel |
| Conduit Box Position | F1 |
| Design Code | B |
| Duty | Continuous |
| Enclosure Design | TENV |
| Finish | Epoxy Coated |
| Frame | 182TC |
| Frame Material | Steel |
| Frame Size | 182TC |
| Frequency | 60 Hz |
| Full Load Amps | 5.8/2.9A |
| Full Load Torque | 6 lbs.-ft. |
| Hp | 2 hp |
| Insulation Class | Class H |
| Inverter Code | Inverter Duty |
| Leads | 9#16 |
| Line-line Res. @ 25° C | 6.2 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 25 lbs.-ft. |
| Magnetizing Amps | 3.4/1.7A |
| Max. Rpm | 6000 RPM |
| Motor Enclosure Design | Totally Enclosed Non Ventilated |
| Motor Mounting Position | Horizontal |
| Motor Type | Three Phase |
|---|---|
| Mounting Type | C Face, Foot Mounted |
| Multiplier | E2 |
| Nema/iec | NEMA |
| No Load Amps | 1.7A |
| No. Of Motor Leads | 9 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 84% |
| Overall Length | 17.77" |
| Phase | 3 |
| Power Factor | 73 |
| Proprietary | No |
| Pull-up Torque | 22 lbs.-ft. |
| Pulley Face Code | C Face |
| Revision | H |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1 1/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 26A |
| Synchronous Rpm | 1800 RPM |
| Temp. Rise @ Rated Load | 62°C |
| Type | 3628M |
| Voltage | 230/460V |
| Wire Size | 16 AWG |
| Xp Class And Group | None |
| Height (cm) | 32.55 |
|---|---|
| Length (cm) | 58.1 |
| Width (cm) | 31.12 |
| HS Code | 85015220 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 31.95 |
| Style | Model | Hp | Frame | Full Load Amps | Nominal Efficiency | Max. Rpm | Type | Wire Size | Revision | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | ZDWNM22937T | 7 1/2 hp | 254TC | 18.2/9.1A | 91% | 5000 RPM | 3940M | 12 AWG | S | $8,923.17 | |
| A | ZDWNM22938T | 10 hp | 254TC | 24/12A | 91.7% | 5000 RPM | 3956M | 12 AWG | S | $9,079.99 | |
| A | ZDWNM3546T | 1 hp | 143TC | 2.9/1.45A | 85.5% | 2700 RPM | 3524M | 18 AWG | G | $4,891.87 | |
| A | ZDWNM3554T | 1 1/2 hp | 145TC | 4.2/2.1A | 86.5% | 4500 RPM | 3533M | 18 AWG | G | $5,139.53 | |
| A | ZDWNM3611T | 3 hp | 184TC | 8.2/4.1A | - | 6000 RPM | 3640M | 16 AWG | A | $5,682.64 | |
| A | ZDWNM3707T | 5 hp | 213TC | 13.4/6.7A | 89.5% | 4000 RPM | 3735M | 14 AWG | Q | $6,106.23 |
