| Item | Severe Duty Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Break-down Torque | 12.4 lbs.-ft. |
| Class | Stock |
| Conduit Box Material | Cast Iron |
| Conduit Box Position | F1 |
| Design Code | B |
| Duty | Continuous |
| Enclosure Design | TEFC |
| Frame | 145TC |
| Frame Material | Iron |
| Frame Size | 145TC |
| Frequency | 60 Hz |
| Full Load Amps | 2.4A |
| Full Load Torque | 3.03 lbs.-ft. |
| Grease Type | Polyrex EM |
| Hp | 2 hp |
| Insulation Class | Class F |
| Inverter Code | Inverter Duty |
| Kvar | None |
| Lead | 3#18 |
| Line-line Res. @ 25° C | 6.22 ohms A Ph/0 ohms B Ph |
| Locked-rotor Torque | 11.5 lbs.-ft. |
| Max. Rpm | 5400 RPM |
| Motor Enclosure Design | Totally Enclosed Fan Cooled |
| Mounting Type | C Face, Footless |
| Multiplier | SD |
| Nameplate Rpm | 3450 RPM |
| Nema/iec | NEMA |
|---|---|
| No Load Amps | 0.823A |
| No. Of Motor Leads | 3 |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Overall Length | 14.58" |
| Phase | 3 |
| Power Factor | 88 |
| Proprietary | No |
| Pull-up Torque | 8.47 lbs.-ft. |
| Pulley Face Code | C Face |
| Revision | Q |
| Rpm | 3400-3600 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 7/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Start Configuration | DOL |
| Starting Amps | 24.9A |
| Synchronous Rpm | 3600 RPM |
| Temp. Code | T3 |
| Temp. Rise | 42°C |
| Temp. Rise @ Rated Load | 35°C |
| Temp. Rise @ S. F. Load | 42°C |
| Type | 0535M |
| Voltage | 460V |
| Wire Size | 18 AWG |
| Base Indicator | None |
| Xp Class And Group | None |
| Height (cm) | 38.42 |
|---|---|
| Length (cm) | 54.93 |
| Width (cm) | 40.96 |
| HS Code | 85015220 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 37.35 |
| Style | Model | Hp | Frame | Mounting Type | Nameplate Rpm | Conduit Box Position | Power Factor | Overall Length | Shaft Dia. | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | VECP82333T-4 | 15 hp | 254TC | C Face, Footless | - | F1 | 85 | 25.28" | 1 5/8" | $5,224.93 | |
| A | VECP82334T-4 | 20 hp | 256TC | C Face, Footless | 1800 RPM | F1 | 87 | 25.28" | 1 5/8" | $5,538.53 | |
| A | VECP82394T-4 | 15 hp | 254TC | C Face, Footless | 3510 RPM | F1 | 89 | 25.28" | 1 5/8" | $5,359.19 | |
| A | VECP83583T-4 | 1 1/2 hp | 143TC | C Face, Footless | 3450 RPM | F1 | 83 | 14.58" | 7/8" | $1,815.46 | |
| A | VECP83584T-4 | 1 1/2 hp | 145TC | Not Applicable | - | W6 | 72 | 14.56" | 7/8" | $1,888.59 | |
| A | VECP83587T-4 | 2 hp | 145TC | C Face, Footless | - | W6 | 74 | 14.56" | 7/8" | $1,968.74 | |
| A | VECP83660T-4 | 3 hp | 182TC | C Face, Footless | 3450 RPM | F1 | 94 | 16.69" | 1 1/8" | $2,418.60 |
