| Item | Vector Motor |
|---|---|
| Ac/dc | AC |
| Ambient Temp. | 40°C |
| Amps | 0.4A |
| Base Indicator | Rigid |
| Base Rpm | 1800 RPM |
| Base Type | Rigid Base |
| Blower Voltage | 115V |
| Conduit Box Material | Cast Iron |
| Conduit Box Position | F1 |
| Constant Torque | 1000:1 |
| Design Code | B |
| Duty | Continuous |
| Enclosure Design | TEBC |
| Frame | 143TC |
| Frame Material | Iron |
| Frame Size | 143TC |
| Frequency | 60 Hz |
| Full Load Amps | 3/1.5A |
| Hp | 1 hp |
| Insulation Class | Class H |
| Inverter Code | Inverter Ready |
| Leads | 9#18 |
| Magnetizing Amps | 2/1A |
| Max. Rpm | 6000 RPM |
| Motor Enclosure Design | Totally Enclosed Blower Cooled |
| Motor Mounting Position | Horizontal |
|---|---|
| Motor Type | Three Phase |
| Mounting Type | Rigid Base |
| Multiplier | E2 |
| Nema/iec | NEMA |
| No. Of Motor Leads | 9 |
| No. Of Poles | 4 |
| No. Of Speeds | 1 |
| Nominal Efficiency | 87.5% |
| Overall Length | 19.15" |
| Phase | 3 |
| Power Factor | 67 |
| Proprietary | No |
| Pulley Face Code | C Face |
| Revision | K |
| Rpm | 1700-1800 RPM |
| Service Factor | 1 |
| Shaft Dia. | 7/8" |
| Shaft Ground Indicator | No Shaft Grounding |
| Shaft Rotation | Reversible |
| Synchronous Rpm | 1800 RPM |
| Type | 0524M |
| Voltage | 230/460V |
| Wire Size | 18 AWG |
| Xp Class And Group | None |
| Height (cm) | 32.55 |
|---|---|
| Length (cm) | 58.1 |
| Width (cm) | 31.12 |
| HS Code | 85015100 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 29.25 |
| Style | Model | Voltage | Hp | Full Load Amps | Frame | Nominal Efficiency | Nameplate Rpm | Speed Range | Max. Rpm | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | IDM2276T | 230/460V | 7 1/2 hp | 21.4/10.7A | 254TC | 91% | 1180 RPM | - | 5000 RPM | $9,035.94 | |
| A | IDM2332T | 230/460V | 10 hp | 28.4/14.2A | 256TC | 91.7% | 1180 RPM | - | 5000 RPM | $11,040.41 | |
| A | IDM2333T | 230/460V | 15 hp | 36.2/18.1A | 256TC | - | - | - | 5000 RPM | $6,208.13 | |
| A | IDM2333T-5 | 575V | 15 hp | 14.5A | 256TC | - | - | - | 5000 RPM | $6,208.13 | |
| A | IDM2334T | 230/460V | 20 hp | 48/24A | 256TC | - | - | - | 2700 RPM | $6,631.21 | |
| A | IDM2334T-5 | 575V | 20 hp | 19A | 256TC | 93% | - | - | 2700 RPM | $6,631.21 | |
| A | IDM3581T-5 | 575V | 1 hp | 1.2A | 143TC | 85.5% | - | - | 6000 RPM | $2,894.16 |
