| Item | DC Motor |
|---|---|
| Ac/dc | DC |
| Ambient Temp. | 40°C |
| Amps | 98.6A |
| Armature Amps | 98.6A |
| Armature Voltage | 500V |
| Base Indicator | Rigid |
| Base Rpm | 1750 RPM |
| Brushes | 2/36024-3 |
| Class | Stock |
| Conduit Box Position | F1 |
| Duty | Continuous |
| Duty Cycle | Continuous |
| Enclosure Design | DPFG |
| Field Amps | 5.86/2.93A |
| Field Amps Hot | 2.6-3.5/1.75A |
| Field Voltage | 150/300V |
| Field Winding Type | Stab Shunt |
| Frame | 365-6AT |
| Frame Material | Steel |
|---|---|
| Frame Size | 365-6AT |
| Hp | 60 hp |
| Insulation Class | Class F |
| Max. Ambient Temp. | 40°C |
| Max. Rpm | 2100 RPM |
| Motor Enclosure Design | Dripproof Fully Guarded |
| Motor Mounting Position | Horizontal |
| Mounting Type | Rigid Base |
| Multiplier | N2 |
| Nema/iec | NEMA |
| Overall Length | 35.88" |
| Pcode | C |
| Rpm | 1750/2100 RPM |
| Service Factor | 1 |
| Shaft Dia. | 2 3/8" |
| Type | T |
| Voltage | 500V DC |
| Height (cm) | 133.35 |
|---|---|
| Length (cm) | 133.35 |
| Width (cm) | 83.82 |
| HS Code | 85015230 |
|---|---|
| Country Of Origin | US |
| Weight (kg) | 353.25 |
| Style | Model | Hp | Frame | Rpm | Brushes | Shaft Dia. | Overall Length | Field Winding Type | Motor Enclosure Design | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | D50100P | 100 hp | 368AT | 1750/2000 RPM | 2/36024-3 | 2 3/8" | 38.88" | Straight Shunt | Dripproof Fully Guarded | $66,986.69 | |
| A | D50125P | 125 hp | 407AT | 1750/2000 RPM | 2/40019-3 | 2 5/8" | 40.13" | Straight Shunt | Dripproof Fully Guarded | $77,042.33 | |
| A | D50150P | 150 hp | 409AT | 1750/2000 RPM | 2/40019-3 | 2 5/8" | 44.34" | Straight Shunt | Dripproof Fully Guarded | $96,056.36 | |
| A | D5040P | 40 hp | 328AT | 1750/2100 RPM | 2/28610-2 | 2 1/8" | 38.58" | Straight Shunt | Dripproof Fully Guarded | $37,041.93 |
