| Item | Swivel Plate Caster |
|---|---|
| Bearing Type | Double Ball |
| Brake Type | Side Strap |
| Caster Brake Included | Yes |
| Caster Brake Type | Side Pedal Brake |
| Caster Frame Material | Steel |
| Caster Load Rating Range | 0 lbs. to 299 lbs. |
| Caster Material | Polyolefin |
| Caster Product Group | Swivel Caster With Brake |
| Caster Sub-type | Swivel |
| Caster Type | Swivel |
| Caster Wheel Material | Polyolefin |
| Caster Wheel Shape | Standard |
| Core Color | Gray |
| Core Material | Polypropylene |
| Durometer | 65 Shore D |
| Frame Finish | Zinc Plated |
| Frame Material | Steel |
| Hole Pattern | D |
| Includes Thread Guards | No |
| Inside Bolt Hole Spacing | 1 3/4" x 3" |
| Load Rating | 220 lbs. |
| Lock Type | No Lock Included |
| Mounting Bolt Dia. | 5/16" |
| Mounting Height | 5 5/8" |
| Mounting Plate Bolt Hole Pattern | D |
| Mounting Plate Size | 2 3/4" x 3 3/4" |
|---|---|
| Mounting Plate Size & Bolt Hole Pattern | 2 3/4" X 3 3/4" ( D ) |
| Non-marking | Yes |
| Number Of Mounting Holes | 4 |
| Number Of Wheels | 1 |
| Outside Bolt Hole Spacing | 1 3/4" x 3" |
| Plate Size | 3 3/4" x 2 3/4" |
| Plate Thickness | 0.109" |
| Plate Type | D |
| Raceway Type | Double Ball |
| Swivel Construction | Kingpin |
| Swivel Lock Type | No Lock Included |
| Swivel Raceway Type | Double Ball |
| Tread Shape | Standard |
| Wheel Bearing Type | Delrin |
| Wheel Bearings | Plain Bore |
| Wheel Color | Black |
| Wheel Core Material | Plastic |
| Wheel Diameter | 5" |
| Wheel Material | Polyolefin |
| Wheel Width | 1 1/4" |
| Wheel/tread Color | Black |
| Wheel/tread Hardness | 65 Shore D |
| Wheel/tread Hardness Rating | Hard |
| Wheel/tread Material | Polyolefin |
| Height (cm) | 0.1 |
|---|---|
| Length (cm) | 25.4 |
| Width (cm) | 20.32 |
| HS Code | 8716903000 |
|---|---|
| Country Of Origin | BR |
| Weight (kg) | 0.643 |
| Style | Model | Inside Bolt Hole Spacing | Outside Bolt Hole Spacing | Caster Load Rating Range | Wheel Bearing Type | Caster Brake Type | Load Rating | Mounting Height | Wheel Width | Price (ex. VAT) | Cart |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 1NUX5 | 3" x 3" | 2 5/8" x 3 5/8" | 300 lbs. to 999 lbs. | Roller | Side Pedal Brake | 900 lbs. | 7 1/2" | 2" | $49.11 | |
| B | 1NUX8 | 3" x 3" | 2 5/8" x 3 5/8" | 300 lbs. to 999 lbs. | Roller | Side Pedal Brake | 900 lbs. | 9 1/2" | 2" | $104.66 | |
| C | 1NUY2 | 3" x 3" | 2 5/8" x 3 5/8" | 300 lbs. to 999 lbs. | Roller | Side Pedal Brake | 750 lbs. | 5 5/8" | 2" | $50.45 | |
| D | 1NUZ7 | 3" x 3" | 2 5/8" x 3 5/8" | 300 lbs. to 999 lbs. | Roller | Side Pedal Brake | 800 lbs. | 5 5/8" | 2" | $36.04 | |
| E | 1NVC1 | 3" x 3" | 2 5/8" x 3 5/8" | 1000 lbs. to 2999 lbs. | Roller | Side Pedal Brake | 1000 lbs. | 5 5/8" | 2" | $39.90 | |
| E | 1NVC4 | 3" x 3" | 2 5/8" x 3 5/8" | 1000 lbs. to 2999 lbs. | Roller | Side Pedal Brake | 1000 lbs. | 6 1/2" | 2" | $51.55 | |
| E | 1NVC7 | 3" x 3" | 2 5/8" x 3 5/8" | 1000 lbs. to 2999 lbs. | Roller | Side Pedal Brake | 1200 lbs. | 7 1/2" | 2" | $58.60 |
